Showy Pergola with a 4ft Cantilevered Roof

This bright white pergola has a 4′ cantilevered roof that reaches back toward the house for full coverage of the patio. Western Timber Frame™ built it as an 8,000 Series pergola kit with a full arched knee brace and keystone on the front, Crescent Step beam and rafter ends, and a TimberVolt® Inferno® power post.

A cantilevered pergola roof covers space that would otherwise be too tight for another post. It also adds visual interest and more protection right where it is needed, next to the house.

White timber pergola with a full arched knee brace and keystone shading a patio at the back of a gray-sided home
The white pergola with its arched front knee brace.

Key Takeaways

  • Cantilever: the roof extends 4′ back toward the house without another post
  • Size: 22′ × 15′ 8″ roof in the 8,000 Series
  • Details: a full arched front knee brace with a keystone and six Classic braces
  • Power: a TimberVolt® Inferno® post for outlets, USB charging, lights, and a fan

What Does the Cantilevered Roof Add?

The roof measures 22′ × 15′ 8″ overall, and the side with the cantilevered extension measures 19′ 8″. By extending the roof back toward the house instead of adding a post, the pergola covers the whole patio while keeping the doors and walkway clear.

Side view of a white timber pergola with a cantilevered roof extending back toward the house over a patio
The cantilever reaching back toward the house.
White timber pergola over a patio above a stone retaining wall and stairs beside a home with a garage below
The pergola above the stone wall and stairs.

What Are the Specifications?

Timber series8,000 Series
Roof size22′ × 15′ 8″
Cantilevered side19′ 8″, with a 4′ cantilever back toward the house
Posts6″ × 6″
Front knee braceFull arched with a decorative keystone
Other knee bracesSix, Classic style
Beam and rafter endsCrescent Step profile
StainWhite
PowerTimberVolt® Inferno® power post
Front of a white timber pergola with an arched knee brace at the top of a brick-edged stairway between evergreens
The arched knee brace at the top of the stairs.
White timber pergola on a raised patio above a rock garden and stairs, with bare winter trees and blue sky
Above the rock garden on a sunny winter day.

What Does the TimberVolt® Inferno® Power Post Include?

The TimberVolt® Inferno® power post runs wiring inside the timber, so power is right where it is needed:

  • A recessed plug with a weather-resistant cover
  • A GFCI outlet for protection, with a weather-resistant cover
  • An outlet just above the GFCI with two USB ports
  • A double switch halfway up the post, one for lights and one for a fan
  • An upper TV outlet with two USB ports
  • Separate connections at the top of the post for lights and a fan, both on the double switch

Beautiful job, and thank you for sharing!

Questions About Cantilevered Pergolas

What is a cantilevered pergola roof?

A cantilevered roof extends past the posts. On this pergola, the roof reaches 4′ back toward the house, covering space that would be too tight for another post.

Why choose a cantilevered roof?

It covers more of the patio without adding posts, keeps walkways and doors clear, adds protection close to the house, and gives the pergola a more interesting profile.

What does the TimberVolt® Inferno® power post include?

This post includes a recessed plug, a GFCI outlet, outlets with USB charging, a TV outlet, and a double switch for lights and a fan, each with a weather-resistant cover.

Can a pergola power a ceiling fan?

Yes. A standard TimberVolt® power post can handle a ceiling fan, with power routed up to the fan and lights at the roof.

Is shipping included?

Freight is included in the lower 48.
