TRADITIONAL
Old-World Craftsmanship

For centuries Dovetail mortise joints have been used for wood-to-wood joinery. We have used dovetail mortise and tenon joinery on our pergolas and pavilion for many years, and our customers can attest to the strength and durability of The Dovetail Difference® —a patented design of Western Timber Frame™.

With a thorough understanding of load paths and design properties, well-seasoned timbers with the mortise and tenon joint systems have supported wide open spaces —including cathedral ceilings, great rooms in castles, commercial constructions, expanded bridges and more —structures have lasted for centuries —sometimes millenniums.

cantilever pergola plan
cantilever roof pergola plancantilevered attached diy pergola plan

CANTILEVERED
ShadeScape® Shade Shelters

A cantilevered shelter is not a fit for every outdoor living environment. There are however, many possibilities in adding a cantilevered roof on an outdoor shade shelter. This simple step-by-step informational guide may help you decide if a cantilevered roof is right for you.

#DIYCantileverPergolaGuide Heavy-Duty Pavilion

Informational Cantilevered ShadeScape®
SHADE SHELTER GUIDE

cantilevered roof pergola pool

#DIYCantileverPergolaGuide

ShadeScape® Shade Shelters
BENEFITS

deck cantilevered roof pergola

ShadeScape® Shelters are a great way to add value to your home, business, deck or yard area. A cantilever roof gives more canopy without additional side posts or support beams with knee braces. We also hide all the fasteners that attach the pergola to your home, so you do not have to see rusty metal hangers and hardware. You only see a beautiful wood-to-wood connection.

CONNATURAL
Wood-to-Wood
CONNECTIONS

Targeted
SHADE

A cantilevered roof on an arbor, awning, gazebo, pavilion or pergola is the perfect way to extend protection and shade to a targeted area. For example, you could have an area that you would like to set up your barbecue without taking up space in your living area. A designated portion of the roof would extend to provide shade covering the cooking space.

diy pergola plan with cantilevered roof design

#DIYCantileverPergolaPlan Cantilever Pergola Plan

Eye-catching
AESTHETIC APPEAL

There is an importance of beauty in architecture. Aesthetic appeal is based upon personal taste. Certain architectural forms do make more aesthetic appeal to the masses than others.

Similar to a suspended table or bed a cantilever roof feels free and unfettered jutting out into the open air. It is a design feature that has been extremely popular in outdoor living environments.

Our Design Managers are experts in outdoor living environments to help you create a truly inviting outdoor living environment that fits your needs and your budget.

round roof

#DIYRoundPergolaPlan Cantilever Pergola Kit Plan

Maximizes
AVAILABLE SPACE

diy trellis plan

#DIYTrellisPlan

Cantilevered ShadeScape® kits provide a clear space underneath the beam without any supporting columns or bracing, maximizing an area to its fullest potential.

Types of Shade
SHELTERS

sloped cantilever diy-pavilion plan

#DIYPavilionPlan

trellis for shade

#DIYTrellisPlan

multiple design plan

#DIYPergolaPlan

Cantilever
PERGOLA

cantilever fullwrap roof

A cantilever pergola is a backyard structure made with posts, beams, and supporting cross beams which hold up rafters and top shade planks creating a lattice-type roof.

The primary purpose of an cantilever Pergola is to create an outdoor space, with additional shade and protection. We help you create an inviting and comfortable outdoor room, which you can dec- orate and furnish. Having an attached pergola allows you to extend your home outdoors, creating inviting spot where you and your family will enjoy spending time.

We help you design and create a beautiful multi-purpose cantilever Pergola for all your family events, social gatherings, romantic evenings, and general purpose entertaining. Don’t let limited indoor space crash your party, invite more people and have more fun with your friends outside.

All cantilever pergola kit is designed to provide the perfect amount of shade and protection from the sun to exactly where you need it. Now you can enjoy fresh air, a calm breeze, and little gentle sunshine. It is time to relax under a beautiful Timber Cantilevered Pergola, love your backyard, and see the beauty of the world around you.

Note: With shade planks that are spaced closer together, Western Timber Frame™ ShadeScape® attached Pergola Kits provide 80% Shade Coverage; which is approximate the same shade coverage you would get with a tree.

Cantilever
PAVILION

A structure made of posts and beams supporting a pitched roof that is completely covered with roofing materials, providing complete shade and protection. An Cantilever Pavilion Roof expands the amount of protection from inclement weather.

solid wood pavilion dovetailed

Cantilever
TRELLIS

swimming pool shade trellis

An architectural structure made with posts and beams in single file, supporting a row of rafters on top, often latticed and used to support climbing plants. A trellis is often used to create borders, walls and privacy screens. A cantilever trellis roof is the perfect solution for additional shade without taking additional space.

Cantilever
GAZEBO

A Gazebo is a pavilion built for the express purpose of taking in the surrounding view. Gazebo means: a place from which to gaze. Gazebos are traditionally hexagonal in shape. A ShadeScape® Gazebo can be have a cantilevered roof on any or all sides.

A gazebo with two addes pergola wings on the sides.

Cantilever
ARBOR

An architectural structure made with posts and beams in single file, supporting a row of rafters on top, often latticed and used to support climbing plants. A trellis is often used to create borders, walls and privacy screens. A cantilever trellis roof is the perfect solution for additional shade without taking additional space.

The Cantilever roof is an extension of the timber frame outdoor shade shelter.
Foremost of importance is to take a look at the overall design the cantilever extends from.

We help you design and build your kit, from
CONCEPT to CREATION

exploded attached pergola plan

We help you design your kit; then we ship your kit right to your door. Each kit is pre- marked and includes easy step-by-step instructions. With easy interlocking joints, your kit will be ready to just drop into place, somewhat similar to the toy “Lincoln Logs” we used to play with as kids. The pieces are easy to assemble and interlock into place. We do the hard work for you.

Customized
DESIGN

cantilever roof pergola
cantilever roof pergola
arch top pergola

Western Timber Frame™ is different; we do not fit you with a pre-made, cookie cutter kit. These are not kits that you can buy in your average big box store. All of our kits are custom built to match your requirements and to fit your back yard.

We call our pergolas and pavilions a kit because we ship them to your door ready to assemble. However, due to the heavy timbers, and their custom nature your Structure will not look like a typical kit. Your pergola will be an outstanding hand crafted room in your backyard.

Building a Project with Western Timber Frame™ is a simple process you can do in person, over the phone, or via email.

The Dovetail Difference®

The Dovetail Difference® is an unprecedented masterpiece of architectural engineering. A simple, yet strong design provides greater stability and heavier load capacities.

It allows the wood to perform as nature intended, expanding and contracting while keeping the joints tight and secure throughout the years.

Helps to Eliminate Gaps and Exposure

The Dovetail Difference® has a trapezoidal angle shaped dovetail (mortise) that interlocks with another angled (tenon) creating a snug fit. This snug fit allows for the natural seasonal expansion and contraction of timber pergola joints.

the dovetail difference

Tight fitting joints in which little movement is allowed between the mortise and tenon can shoulder greater loads than loose, bolt or peg joints. The dovetail mortise and tenon gives the timber the ability to expand and contract while remaining tight, minimizing gap exposure, reducing twisting and warping.

The patented The Dovetail Difference® also eliminates virtually all exposed hardware, bolts, screws, hangers or other mechanical fasteners unless they are decorative in nature.

Mortise and tenon joints have soundly stood stronger through centuries of architectural constructions because it allows for the wood to naturally expand and contract while maintaining its integral shape without nail or glue construction.

eliminate exposed hardware
ocean timber frame pavilion

Buildings are considered to be solid, immobile structures, yet we live in an environment of continual motion where even the most solid structures will move in waves up and down as well as side-to-side.

Seasoned timbers of this scale with The Dovetail Difference® naturally move and adjust to this persistent micro-motion.

Superior Strength

Independent engineering has shown that dovetail joints are 500% greater in strength and load carrying capacity as compared to traditional hangers. They can withstand strong 120+ MPH winds, heavy mountainous snows, and they have strong, rigid corners. Not only do you get superior strength, but this design makes installation faster and more convenient.

pressure test dovetail mortise joint

Picture: On the test pictured above, The Dovetail Difference® dovetail didn’t break until it hit over 11,000 lbs!

pavilion test

Traditional Craftsmanship

For centuries Dovetail mortise joints have been used for wood-to-wood joinery. We have used dovetail mortise and tenon joinery on our pergolas and pavilion for many years, and our customers can at- test to the strength and durability of The Dovetail Difference®.

With a thorough understanding of load paths and design properties, well-seasoned timbers with the mortise and tenon joint systems have supported wide open spaces including cathedral ceilings, great rooms in castles, commercial constructions, expanded bridges and more structures have lasted for centuries, sometimes millenniums.

Beam-to-Post Application

Our unique drop-in rafter layout system allows for a quick, snap-together Beam-to-Post application that prevents warping and twisting for unmatched quality and durability.

Saves time in layout and assembly of your beams and posts. Our experienced craftsman does the hard work for you.

beam to post
guide slot rafters

Drop-in Rafter Layouts

Another unique feature that we include with every timber pergola kit is drop-in rafter layouts.

There are two main benefits of the drop-in rafter layout. The first is ease of installation. Because the timber beam that supports the rafters is already marked and slotted, you do not have to measure anything or try to figure the proper spacing of your rafters.

The second benefit of the drop-in rafter layout is that it helps prevent warping and twisting of the rafters.

Heavy Timber Kits

Pergola with tables

We ship ShadeScape® Pergolas, Pavilions, and Arbors daily throughout North America. These kits range from 2,500 – 11,000 lbs. (they often larger on commercial or large custom projects).

The average ShadeScape® shipment weighs over 5,500 lbs. We transport the kit by freight because of the sheer mass and weight of the timbers.

ShadeScape® Timbers are not a small bundle of wood or dimensional lumber from your local big box hardware store. These structures are NOT like your average $800 – $2,000 cookie cutter pergola kit that weighs somewhere around 200 lbs. – 380 lbs and fits inside 2-3 cardboard boxes.

timber beam ends
truck pergola kit

Packaged ShadeScape® shelter kits have an average of 16 feet in length, 36 in height, and 48 in width. We build custom heavy duty pallets to ship these ShadeScape® kits to sustain the mass and weight of the timbers.

When we ship your kit, it is going to come on the back of a semi-trailer. Remember, our structures are 10 to 30 times the weight of a big box store kit.

our guys in the shop with timber beams

Despite their massive size, they are easier and quicker to assemble than smaller less sturdy kits. Western Timber Frame™ utilizes our patented dovetail joint method for our beam-to-post connections. Everything is pre-cut, pre-finished, and pre-fitted. We make it easy to assemble.

Timber frame pavilion in shop assemble

Conventional Timber Framing

Most Timberwrights build a pergola or pavilion with a conventional mortise and tenon notch. They use a chainsaw to cut a notch out of the post and beam. They cut out a “U” shape through the post on both sides, and then they slide them through each other, lock the joint in place, and then bolt it in place.

If they are very skilled, they can get a pretty tight seam. It can look great. However, after six months to a year, sometimes two years, you start getting gaps in joints. That is the nature of wood. Wood expands and contracts. So thin posts and cuts can become brittle and break off, making the timber structure look terrible.

traditional timber frame
conventional dovetail timber cracking

Conventional Joint After Only 18 Months

What Makes Us Different

Our Timberwright Craftsmen take great pride in their attention to the small details.

We smooth all exposed edges on our heavy timbers with a 1⁄4” round. The rounded edge allows the timbers to retain their rough appearance, with a touch of refinement.

Our top “shade planks” are spaced closer together, when compared to other pergolas offering additional shade and a unique look.

We use true to size rough-sawn timber for all components rather than standard smaller ‘dimensional’ lumber. We also use taller and wider rafters on our double tier roof as compared to what you will find elsewhere.

We Pre-Fit Your Kit to make sure that your installation is easy and flawless.

All of our Kits are delivered ready to assemble with all parts pre-cut, drilled and notched with roof layout, and pre-stained with two coats of premium grade UV-rated exterior semi-trans- parent stain, which makes installation even faster, more convenient and ensures high quality!

Our unique mortised joints not only allow for a long-lasting, perfect joint, but it also virtually eliminates the use of unsightly galvanized brackets, hangers, and bolts.

birthday pavilion
dovetail difference

SUPERIOR QUALITY

• 500% Stronger Than Hangers and Bolts
• Structural Integrity
• Quick Installation
• Pre-cut Slots
• Fast Alignment
• Simple Installation
• No Exposed Hardware
• Authentic Craftsmanship

INCLUDED HARDWARE

Each pergola comes complete with all hardware and post mounts needed for installation. Our unique assembly method allows the Timber pergola to have a sleek final appearance virtually eliminating all visible screws, lags, bolts, hangers or mechanical fasteners.

hardware included

STAIN COLOR OPTIONS

To make sure that your pergola looks great and lasts, we only use the highest quality premium grade stain. All stain colors have the highest UV-rating possible and are water based to make them durable and safe. For your convenience, we pre-stain all kits before shipping.
Note: Your stain color and your other standard options are completely free. With every kit, we include your choice of Stain, Knee Brace, and Beam Profile.

wild olive stain
early american
rich cordoba stain
canyon grey
Alpine White Stain
rich sequoia stain
ebony black stain
natural stain
beach sand stain
bleached stain
arrows for bleach
bleach stain

ShadeScape® Series

The ShadeScape® Series represents excellence in world-class architecture. We utilize rough-sawn heavy timbers to create the ultimate outdoor living structures.

The Western Timber Frame ShadeScape® Series offer an extensive range of size options to create superior outdoor living experiences.

Each landscape is unique in size, location, and application. The ShadeScape® Series can be customized to fit any outdoor environment.
True to size rough-sawn timbers provide timeless quality while embracing authentic old-world craftsmanship.

6,000 Series ShadeScape® Pergola Kit

6000 series

6,000 SERIES
• 6″ x 6″ Posts
• 3″ x 10″ Beams
• 2″ x 8″ Rafters
• 2″ x 4″ Shade Planks
• 2″ x 8″ Knee Braces

2,925 Pounds
886 Board Feet

8,000 Series ShadeScape® Pergola Kit

8000 series timber pergola kit

8,000 SERIES
• 8″ x 8″ Posts
• 4″ x 12″ Beams
• 3″ x 10″ Rafters
• 2″ x 6″ Shade Planks
• 3″ x 8″ Knee Braces

10,000 Series ShadeScape® Pergola Kit

10000 series pergola kit

10,000 SERIES
• 10″ x 10″ Posts
• 6″ x 12″ Beams
• 4″ x 10″ Rafters
• 3″ x 6″ Shade Planks
• 4″ x 8″ Knee Braces

12,000 Series ShadeScape® Pergola Kit

12000 series kit pergola

12,000 SERIES
• 12″ x 12″ Posts
• 8″ x 12″ Beams
• 6″ x 8″ Rafters
• 4″ x 6″ Shade Planks
• 6″ x 8″ Knee Braces

Light Up Your ShadeScape®

pergola lights

Don’t overlook adequate lighting in your yard. Outdoor Lights extend usability, lengthening the number of hours your family can enjoy in your outside living room. Solar LEDs, garden path lights, fire braziers, candles, a fire pit, etc. are some of the many possibilities.

Lighting is not the most expensive outdoor improvement, yet it adds value to a home; showing off your ShadeScape® Structure while enhancing the beauty of the landscape.

TimberVolt® Outdoor Integrated Power

We designed the new TimberVolt® power system specifically for outdoor wood arbors, gazebos, pavilions, and pergolas. The TimberVolt® system is pre-drilled with a hole down the center of one post to accommodate all of your electrical and lighting needs.

It is all concealed and out of sight and also offers protection from the elements with electrical boxes with covers installed. The TimberVolt® series eliminates conduits, nails, unsightly and unsafe exposed wires and reduces the cost of, or even prevents the need to hire an electrician.

TimberVolt® power posts allow you to maximize your outdoor time. Timber- Volt® posts are pre-drilled through the entire shaft. Our pre-wiring options will save time and money by making it easy to bring power to your outdoor living area. Your structure will be ready to use the moment you install it; no need to wait for someone to wire it up.

You can add as many TimberVolt® posts as you need, and configure their locations as much as you like. The Dragon and Inferno models provide grid-free power in a self-contained unit. The Dragon and the Inferno models use GFI plugs to protect you and your equipment. Just connect the male plug to a generator, and you are ready to go.

Meet Your Design Manager

Each ShadeScape kit is custom for your needs and your backyard. Our Design Managers work with you to determine what your needs are for your unique situation. They’re experts in out- door living environments. They work for you to help you create a truly personal outdoor liv- ing space based on your needs. They’ll listen to you, and in turn, ask you questions to help you create a truly inviting outdoor living envi- ronment that fits your needs and your budget.

This whole process usually takes less than 20 minutes. Total turn around time to delivery is about two weeks. In our busy season, it can be as long as three weeks. You only need to know the color and the ‘look’ you want to get started. Our Design Managers know the industry and can pull your project together with just a few suggestions.

Your Designer will guide you step-by-step from planning, measuring your yard, and getting your kit built and shipped.

Most importantly, we focus on designing to fit your lifestyle. We want your outdoor living space to be beautiful. We do this through a tailored approach, to guarantee a perfect fit.

Dedicated design manager

Your Design Manager will make sure that your project is a Success.

• He will help you measure and choose the right size for your yard.
• You will see what you’re getting, with free 3D Renderings & Design.
• Get easy HOA and engineering approval, when our experts help you.
• We work with your subcontractors, to get your project done on time.
• Your Designer make sure that your project stays within your budget.

Installation

“We researched quite a few sites and talked to many people before investing in a Western Timber Frame pergola. What sold us was the dove tails! The or- dering process was quite simple. It arrived in a nice bundle. We were able to put up our Western Timber Frame pergola with only 3 of us. It was amazingly simple.” Teri Mullins, Kentucky

pergola kit uninstalled
setting out kit
installation
installing
installed pergola after
with lights on pergola

We make installation simple. We test fit every single piece before we ship it to you to ensure that your installation will be easy and fun. With very little carpentry skills, a few basic tools, and the help of a friend or two, you can install your Timber Pergola in one afternoon.
Your kit will be have detailed instructions for a fast and easy assembly. The joints will have a clean, tight joint finish without the view of unsightly hardware.

All our pergola kit parts are pre-cut, pre-drilled, and pre-notched with easy interlocking corners and drop-in rafter layouts.
We provide instructions in our installation manual as well as technical support from one of our installers at your request. Our support team is available during the week to answer any questions you have via phone or email.

DIY Installation

We are very happy to assemble and install your pergola for you, just give us a call. However, if you are just feeling intimidated by the massive size of these timber frame pergola kits, you will find it quite easy to install, and we are there to ensure your installation is successful.
