The gentle slope of a hip roof with its trapezoidal sides and pyramid-like elegance is a graceful traditional design that pleases the eyes and can be constructed in a combination of various unique styles.

The hip roof, also referred to as a hipped roof is a symmetrical rectangular construction with two hips meeting at either end with four sloping uniform sides meeting at a single peak. When the hip is equal on all four sides it is sometimes called a pavilion roof or a pyramid roof. The external angle to which the sloping adjacent sides meet is the hip. To the degree that the hip slopes is ascribed as the hip bevel.

A hipped roof is more durable, often used in more advanced architecture adding quality and solidness to a home or shade structure. Hipped roofs on shade structures e.g. she sheds, man caves, hobby huts, etc. are popular in strong wind regions and coastal locations giving an appealing look to the property and is considered the best choice for a shed covering.

The hip roof is sound and great choice for a pavilion as well. Check out today’s featured DIY timber kit, a timber frame pavilion with a hipped roof and TimberVolt™  integrated self-contained power system.:

10,000 Series ShadeScape™ Hipped Roof DIY Pavilion Kit

hipped roof pavilion
ShadeScape™ 10,000 Series DIY Pavilion Kit Specs

Posts: 10″ x 10″ x 10′
TimberVolt™: Pre-wired Inferno post
Roof: 22′ x 24′ Hipped
Wood Type: Douglas fir
Pavilion: Free-Standing
Brace Size: 3×8
Rafters: 3×8
Shade Planks: Tongue & Groove
Beam and Rafter Profiles: Roosevelt
Stain Color: Rich Cordoba
Knee Brace Style: Legacy
4 Knife Plates:

inferno power plugs
fan roof pavilion

The TimberVolt™ Inferno model is ideal for charging your smartphones, tablets, and other USB devices, while you watch movies on your outdoor TV that is plugged into one of the main electrical receptacles up top.

The TimberVolt™ Inferno Model Features:

• Male plug with upgraded weather cover
• One GFI for your protection
• Upgraded weather covers
• One upper TV plug with two USB plugs
• One double switch on top for lights
• One separate double switch on top for fan
• Integrated USB outlets

A custom steel insert is on the top to protect the wiring or water lines from being punctured from lags and hardware fasteners throughout the installation process. It includes an electrical box on top with two electrical receptacles to prevent water and debris from going down inside the post. This also provides excellent access for lights, fans and other accessories at the roof.

hip roof pavilion

10,000 Series 22′ x 24′ ShadeScape™ DIY pavilion kit built with old world craftsmanship without the use of nails or glue makes this a stunning place to look up into the clean finished fine woodwork with no unsightly hardware to view.

Patio furniture beneath a 22′ x 24′ ShadeScape™ DIY pavilion kit installed for shade over permeable pavers.

roof pavilion

King post in center of a hipped roof of a DIY old world pavilion kit with mortise and tenon dovetail connections.

Center of the hip roof is the king post giving that handsome architectural dovetail of timberwright artisans. Properly seasoned, well designed timber frame with the mortise and tenon joint system has been proven itself to be the most architecturally responsible material available in its ability to stand against greater wind loads as well as having amazing seismic resilience. In regions where there is the continual and natural occurrences of storms, strong winds, heavy snows and seismic shifting it is especially essential to have a thorough understanding of load paths and design properties. This is an amazing timber pavilion for weighty mountainous snow loads and strong coastal winds and a hipped roof is just an extra bonus for strength to stand against wind and extra resilient with heavy snow.

pavilion hip roof
patio hipped roof pavilion

DIY timber frame pavilion kit featuring a hip roof and an integrated self-contained outdoor power system for an outdoor living room.

The outdoor dining or patio furniture gives a welcoming invitation to converse with family and friends or to just spend some quiet reflective time alone in this private backyard oasis.

hipped roof pavilion

22′ x 24′ DIY pavilion kit featuring a hipped roof of old world craftsmanship, TimberVolt™ integrated and self-contained outdoor power system with outdoor patio furniture.

hipped roof pavilion chairs

22′ x 24′ hipped roof DIY pavilion kit erected over backyard patio with outdoor living room furniture.

There has been a push towards going green with not only more economical construction but proven architectural construction using timber and timber frame. Going green however, does not mean doing without conveniences.

lady lair pavilion power
control pergola

The TimberVolt™ integrated and self-contained power system is convenient and beautiful. The TimberVolt™ Inferno power post is pictured on the far left corner.

power post pavilion kit
