12×20 Oversized DIY Timber Frame Pergola Kit Backyard Remodel




















Corner view of the 20’x 20′, five post timber frame 8000 Series ShadeScape™ DIY pergola kit with lattices over backyard concrete patio. The extra outdoor room gives a relaxed family atmosphere for activities such as cooking, dining and good conversations.
The Bacon Pergola is one of our OverSize pergolas. See more pictures of this pergola in our Oversize Gallery.
Continued from: How to Install a DIY Timber Frame Pergola Kit; Setting the Posts & Beams 6/12 We will put a bolt through once all four corners are done then we will be ready to lay up and get all the posts leveled. We then attach some temporary 2 x 4’s attached to the upper beam and we have it all lined up as in this example pictured right.
This customer must have liked what they saw because we are building this one for them in the near future. Again, Hyrum has done an excellent job in sketching it up and we will be posting the finished product as soon as it is finished and pictures have been taken of it.
Our boys went out on a trip to the open prairies of Wyoming where they installed this beautiful Pergola and Bridge. Take a look at these beautiful pictures and see for yourselves.
Pergola kits come in all shapes and sizes , but today’s featured project is a six-post 8000 Series ShadeScape® pergola, a design of Design Manager Brian Thompson. Early American ShadeScape® 8000 Series 6 Post DFY Pergola Kit Outdoor Power: TimberVolt® Power Post Structure Type: Freestanding Structure Style: Traditional Wood Type: Douglas Fir Size of Timbers: 8000 Series Stain: Early American Beam Profile: Champion Knee Brace Style: Classic Roof Size Dimensions: 12′ x 24′ Footprint Size Dimensions: 10′ x 22′ Overall Structure Height: 11′ Post Size: 8″ Btm of Support Beam Height: 9′ Hardware: 6 Knife Plates #6-PostPergolaKit #EarlyAmericanPergola #RafterChampionProfiles #TimberFrameShade #SolidWoodShadeShelter
